AVK SUPA® NON-TENSILE FLANGE ADAPTOR, PN16

GEOMET® zinc coated grade 8.8 bolts/nuts, WRAS approved EPDM sealings

CHAN

Contact

Chan Chee Leong

Senior Manager, Sales and Marketing

Non tensile flange adaptor for drinking water and neutral liquids, including sewage and waste water free of hydrocarbons, to max 70°C

AVK Supa® is a range of universal straight couplings, step couplings and flange adaptors for cast iron, ductile iron, steel, uPVC and asbestos cement pipes. Supa® couplings are easy to mount due to the GEOMET® anti-friction zinc-aluminium coated bolts and nuts and the ability to deflect up to 4° in all directions. The coated fasteners and the high quality epoxy coating make sure to offer a highly durable corrosion protection.

Variant 603/A-002
Connection: Supa Coupling
Material: Ductile iron
DN: DN50 - DN400
PN: PN 16

Features

  • GEOMET® anti-friction, anti-corrosion zinc/aluminium coating on bolts and nuts
  • Light weight design
  • Up to 4° angular deflection in all directions
  • Drinking water approved EPDM gasket
  • Bolt ends protected with plastic caps
  • Moulded ribs in the gasket absorb all minor imperfections in the pipe
  • The design allows for up to 26 mm variation in outer diameter to cover all pipe materials
  • Epoxy coating according to DIN 3476 and GSK

Downloads

Datasheet
Installation, operation and maintenance manuals

Reference nos. and dimensions:

Scroll for more info
AVK ref. no. Gross Price
MYR		 DN
mm		 D
mm		 L
mm		 L1
mm		 L2
mm		 L3
mm		 Seal range
mm		 Theoretical
weight/kg
603-074-000-4200 285 50 172 159 47 145 98 57-74 3.9
603-085-000-4200 305 50/65 185 159 47 145 98 68-85 4.2
603-106-000-4200 351 80 200 159 47 145 100 84-106 5.0
603-119-000-4200 397 100 254 159 47 145 100 99-119 5.6
603-133-000-4200 404 100 240 159 47 145 101 109-133 5.8
603-157-000-4200 591 125/150 285 184 58 170 111 132-157 9.0
603-183-000-4200 570 150 293 184 56 170 109 157-183 9.3
603-201-000-4200 765 150 313 184 69 170 112 176-201 11
603-215-000-4200 808 200 343 182 110 170 117 193-215 12
603-242-000-4200 892 200 353 182 65 170 117 218-242 13
603-268-000-4200 1,291 250 406 182 110 170 119 242-268 17
603-292-000-4200 1,368 250 406 182 61 170 119 266-292 19
603-306-000-4200 1,559 250 420 182 61 170 119 280-306 19
603-327-000-4200 1,783 300 483 186 59 170 119 301-327 22
603-350-000-4200 1,796 300 483 186 59 170 119 324-350 24
603-396-000-4200 2,363 350 496 226 100 210 161 372-396 30
603-410-000-4200 2,512 350 520 226 100 210 161 384-410 30
603-436-000-4200 2,446 400 597 226 100 210 165 410-436 35
Enquiry
Scroll for more info

Components

1. End cap Plastic
2. Washer Steel, hot dip galvanized
3. Nut Steel gr. 8, zinc plated
4. Bolt Steel gr. 8.8, zinc plated
5. Bracket Ductile iron GJS-450-10
6. Gasket EPDM rubber
7. Adaptor flange Ductile Iron

Test/Approvals

  • WRAS approved materials

Standards

  • Flange drilling to EN1092, PN10/16
  • EN 14525 as reference
